2E-NT & 2E-38NT

For water transfer,

recirculation

and displays

Most commonly used with water displays and air conditioners.
Handles a variety of liquids.
Oil-filled motor housing with a nitrile shaft seal, designed for continuous duty.
Commercial, industrial or residential use, where lesser amounts of liquid must be transferred or recirculated.
Removable polypropylene screen for easy cleaning.
Epoxy coated cast aluminum housing and cover.
Nylon volute and impeller.
2E-38NT can be submersed or used with in-line applications.

Model/Catalogue Number:	2E-NT (502186); 2E-38NT (502286)
Motor Specs:	1/40HP, 115V, 1.7 Amp, 100 Watt, Thermally protected, CSA approved
Capacity (GPH-litres/hr):	250 @1’ head (1136 l@.3m)
Intake (GPH-litres/hr):	2E-NT – hooded; 2E-38NT – 3/8″ (3.2mm)FNPT
Discharge:	¼”MNPT (6mm)
Shut Off (max head):	11½ ft (3.5m)
Pump Pressure:	5 p.s.i
Maximum Liquid Temp:	120°F (49°C)
Power Cord:	10′ (3m)
Dimensions (LxWxH):	5½ x 3½ x 4¾” (14 x 9 x 12cm)
Shipping Dimensions:	7 x 7 x 4-5/8″ (18 x 18 x 12cm)
Weight:	5 lbs (2¼Kg)
Shipping Weight:	5¼ lbs (2.4Kg)
Warranty:	1 year from Deltaquip’s invoice date
