2E-NT & 2E-38NT

2E-NT & 2E-38NT





For water transfer,

    recirculation

    and displays



  • Most commonly used with water displays and air conditioners.
  • Handles a variety of liquids.
  • Oil-filled motor housing with a nitrile shaft seal, designed for continuous duty.
  • Commercial, industrial or residential use, where lesser amounts of liquid must be transferred or recirculated.
  • Removable polypropylene screen for easy cleaning.
  • Epoxy coated cast aluminum housing and cover.
  • Nylon volute and impeller.
  • 2E-38NT can be submersed or used with in-line applications.

Model/Catalogue Number: 2E-NT (502186); 2E-38NT (502286)
Motor Specs: 1/40HP, 115V, 1.7 Amp, 100 Watt, Thermally protected, CSA approved
Capacity (GPH-litres/hr): 250 @1’ head  (1136 l@.3m)
Intake (GPH-litres/hr): 2E-NT – hooded; 2E-38NT – 3/8″ (3.2mm)FNPT
Discharge: ¼”MNPT (6mm)
Shut Off (max head): 11½ ft (3.5m)
Pump Pressure: 5 p.s.i
Maximum Liquid Temp: 120°F (49°C)
Power Cord: 10′ (3m)
Dimensions (LxWxH): 5½ x 3½ x 4¾” (14 x 9 x 12cm)
Shipping Dimensions: 7 x 7 x 4-5/8″ (18 x 18 x 12cm)
Weight: 5 lbs (2¼Kg)
Shipping Weight: 5¼ lbs (2.4Kg)
Warranty: 1 year from Deltaquip’s invoice date
