The 6 Series pumps handle over 38 Imperial gallons per minute…That’s over 2300 gallons per hour!
Model/Catalogue Number:
6-CIA (506158) Automatic, integral diaphragm switch 6-CIA-RFS (506171) Automatic, piggyback mechanical float switch 6-CIM-R (506271) Manual
Motor Specs:
1/3hp / 115V sealed, CSA approved
Capacity (GPH-litres/hr):
2300@1’ head (10,440 l@.3m) or 660@15’ ht (3000 l@4½m)
Discharge:
1½”FNPT (38mm)
Shut Off (max head):
18’(5.5m)
On Level:
6-CIA – 7-10″ (18-25½cm); 6-CIA-RFS – 9-11″ (23-28cm); 6-CIM-R – 1″ (2½cm)
Off Level:
6-CIA – 1-4″ (2½-10.2cm); 6-CIA-RFS – 3-5″ (7½-12.7cm); 6-CIM-R – 1″ (2½cm)
Pump Pressure:
11.4 p.s.i.
Maximum Liquid Temp:
140°F (60°C)
Power Cord:
10′ (25′ can be special ordered)
Dimensions (LxWxH):
8½ x 7 x 8″ (21½ x 18 x 20½cm)
Shipping Dimensions:
10½ x 10½ x 9½” (27 x 27 x 24cm)
Weight:
6-CIA – 7.8 lbs (3½Kg); 6-CIA-RFS – 7 lbs (3.2Kg); 6-CIM-R – 7.4 lbs (3.4Kg)
Shipping Weight:
6-CIA – 8.4 lbs (3.8Kg); 6-CIA-RFS – 7½ lbs (3.4Kg); 6-CIM-R – 8 lbs (3.6Kg)
Warranty:
1 year from Deltaquip’s invoice date
Canadian Owned and Operated
