Attaches to side of pump

Connects to 5MSP, 6 & 8 Series models and others

Allows manual pumps up to ½HP to operate automatically.
Designed to extend pump life and prevent pumps from overheating when running dry.
Suitable for applications where pumps aren’t manned or monitored.
Most commonly used with our 5 MSP Water Wizard® pumps as well as the 6 and 8 series models.
Integrated air hose allows water pressure to actuate switch at predetermined water levels.
Includes piggyback receptacle…plug into outlet and plug pump into it.
Removable at any time, to allow return to manual pump operation.
Can be mounted away from pump for more versatility.

Model/Catalogue Number:	RS-5 (599008)
Electrical Requirements:	Maximum 115 Volt, 10 Ampere, ½ horsepower
On Level:	For 5 MSP – 6-9″ (15.2-22.8cm); for 6 & 8 series – 7-10″ (18-25½cm)
Off Level:	1-4″ (2.54-10.2cm)
Maximum Liquid Temp:	120°F (49°C)
Power Cord:	10′ (3m)
Dimensions (LxWxH):	3½ x 2 x 5-1/8″ (9 x 5 x 13cm)
Shipping Dimensions:	9½ x 9¼ x 2¼” (24 x 23½ x 5¾cm)
Weight:	1 lb (430g)
Shipping Weight:	1 lb 5 oz (600g)
Warranty:	1 year from Deltaquip’s invoice date
